Camera

• Image Sensor: 1/1.8" CMOS
• Pixel: 8 MP
• Max. Resolution: 3840 (H) × 2160 (V)
• ROM: 8 GB
• RAM: 4 GB
• Electronic Shutter Speed : 1/1 s–1/100,000 s
• Scanning System : Progressive
• Min. Illumination:
• 0.005 lux@F1.4 (Color)
• 0.0005 lux@F1.4 (B/W)
• 0 lux (IR light on)
• Illumination Distance: 50 m (164.04 ft) (Warm light); 600 m (1968.50 ft) (Laser)
• Illuminator On/Off Control: Zoom Prio; Manual; Auto; Off
• Illuminator Number: 4 (IR light); 1 (Warm light); 8 (Laser)
• Wiper: Smart wiper

Lens

• Focal Length: 6.0 mm–252 mm
• Max. Aperture: F1.4–F4.8
• Field of View: H: 66.1°–2.2°; V: 39.0°–1.3°; D: 74.1°–2.5°
• Optical Zoom: 42×
• Focus Control: Auto; Semi-auto; Manual
• Close Focus Distance: 0.5 m–2 m (1.64 ft–6.56 ft)
• Iris Control: Auto/Manual/Iris Prio
• DORI Distance
• Lens: W:
• Detect: 120 m ( 393.70 ft)
• Observe: 47.4 m ( 155.51 ft)
• Recognize: 24 m ( 78.74 ft)
• Identify: 12 m ( 39.37 ft)
• Lens: T:
• Detect: 5040 m ( 16535.43 ft)
• Observe: 1990.8 m ( 6531.50 ft)
• Recognize: 1008m ( 3307.09 ft)
• Identify: 504m ( 1653.54ft)

PTZ

• Pan/Tilt Range: Pan: 0° to 360° endless; Tilt: –20° to +90°, auto flip 180°
• Manual Control Speed: Pan: 0.1°/s–240°/s; Tilt: 0.1°/s–100°/s
• Preset Speed: Pan: 240°/s; Tilt: 100°/s
• Preset: 300
• Tour: 8 (up to 32 presets per tour)
• Pattern: 5
• Scan: 5
• Power-off Memory: Yes
• Idle Motion: Preset;Pattern;Tour;Scan
• PTZ Protocol
• DH-SD
• Pelco-P/D (auto recognition)

Intelligence

• Video Metadata: Supports detection of motor vehicles, non-motor vehicles, faces and human bodies, optimization, capturing pictures, and uploading high-quality face snapshots. It extracts attributes from motor vehicles and non-motors, detecting up to 10 attributes for motor vehicles and 8 for non-motor vehicles. It also extracts attributes from human faces and bodies, detecting up to 6 attributes for faces, and 8 for bodies
• IVS (Perimeter Protection): Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; human and vehicle alarm classification; detail camera linkage for positioning and tracking when multiple rules are triggered; cascaded video metadata; linkage tracking; privacy protection
• Face Recognition: Supports face detection, optimization, capturing pictures, uploading high-quality face snapshots and enhancing face images. Attribute extraction is also supported, where 6 attributes and 8 expressions can be detected. Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo. It supports up to 5 face databases, where people can be added one by one or in batches. The face similarity can also be set, and faces can be compared against 10,000 faces
• Smart Tracking: AutoTracking 3.0
• AcuPick: Uses deep learning algorithms and works with backenddevices to accurately match targets, such as people andmotor vehicles, and search through live and recordedvideos to quickly locate targets

Video

• Video Compression: Smart H.265+;H.265;Smart H.264+;H.264;H.264B;H.264H;MJPEG(Sub Stream 1)
• Streaming Capability: 3 streams
• Resolution: 8M (3840 × 2160); 4M (2560 × 1440); 3M (2304 ×1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p(1280 × 720); D1 (704 × 576/704 × 480); VGA (640 ×480); CIF (352 × 288/352 × 240)
• Video Frame Rate:
• Main stream: 8M/4M/1080p/1.3M/720p@(1–25/30 fps)
• Sub stream 1: D1/VGA/CIF@(1–25/30 fps)
• Sub stream 2: 1080p/1.3M/720p/CIF@(1–25/30 fps)
• Bit Rate Control: CBR/VBR
• Video Bit Rate:
• H264: 128 kbps–16384 kbps
• H265: 51 kbps–11776 kbps
• Day/Night: Auto/Color/B/W/Electronic
• BLC: Yes
• WDR: 120 dB
• HLC: Yes
• White Balance： Auto; indoor; outdoor; tracking; manual; sodium lamp;natural light; street lamp
• Gain Control: Auto; Manual; Gain Prio
• Noise Reduction: 2D NR; 3D NR
• Motion Detection: Yes
• Region of Interest (RoI): Yes
• Image Stabilization: Gyroscope EIS
• Defog: Optical
• Digital Zoom: 16×
• Image Rotation: 180°
• Privacy Masking: Up to 24 areas can be set, with up to 8 areas in the same view; color block and mosaic selectable
• S/N Ratio: ≥ 55 dB

Audio

• Audio Compression: PCM; G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G722.1; G729; G723

Network

• Network Port: RJ-45 (10/100 Base-T)
• Network Protocol: HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;IPv6;802.1x;SSL;QoS;FTP;UPnP;ICMP;SNMP;IGMP;ARP;RTCP;RTP; PPPoE;RTMP;Bonjour;NFS
• Interoperability: ONVIF (Profile S & Profile G & Profile T);CGI;SDK
• Streaming Method: Unicast/Multicast
• User/Host: 20 (total bandwidth: 64 M)
• Storage: Micro SD card (512 GB); FTP; NAS
• Browser:
• IE 9 and later versions
• Chrome 41 and later versions
• Firefox 50 and later versions
• Safari 10 and later versions
• Management Software: DMSS;NVR;DSS Pro
• Mobile Client: iOS;Android

Port

• Analog Output: 1 channel (CVBS output, BNC)
• RS-485: 1 (baud rate: 1200 bps–9600 bps)
• Audio Input:1 channel (LINE IN, bare wire)
• Audio Output: 1 channel (LINE OUT,bare wire)
• Alarm Input: 7 (on-off value input: 0–5 VDC)
• Alarm Output: 2 channels
• Alarm Linkage: Capture; preset; tour; pattern; recording; alarm digital output; send email; audio
• Alarm Event: Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection

Power

• Power Supply:
• 36 VDC; 2.23 A (±25%)
• PoE (802.3bt)
• Power Consumption:
• Basic: 17 W
• Max. (Illuminator + PTZ operation + Wiper operation): 41 W
• Power Adapter: Included

Environment

• Operating Temperature: –40 °C to +70 °C (–40 °F to +158 °F)
• Operating Humidity: ≤ 95%
• Protection: IP67;TVS 6000 V lightning proof; surge protection; voltage transient protection
• Anti-corrosion Level: Basic Protection *The products are designed for general use and are applicable even in areas with no specific requirements for anti-corrosion protection.

Structure

• Product Dimensions: 262 mm × 262 mm × 442 mm (10.31" × 10.31" ×17.40") (L × W × H)
• Net Weight: 10.38 kg (22.88 lb)
• Gross Weight: 13.83 kg (30.49 lb)
