| Camera |
| Image Sensor | 1/1.8" CMOS |
| Pixel | 8 MP |
| Max. Resolution | 3840 (H) × 2160 (V) |
| ROM | 8 GB |
| RAM | 4 GB |
| Electronic Shutter Speed | 1/1 s–1/100,000 s |
| Scanning System | Progressive |
| Min. Illumination | 0.005 lux@F1.4 (Color)
0.0005 lux@F1.4 (B/W)
0 lux (IR light on) |
| Illumination Distance | 50 m (164.04 ft) (Warm light);
120 m (393.70 ft) (IR);
600 m (1968.50 ft) (Laser) |
| Illuminator On/Off Control | Zoom Prio; Manual; Auto; Off |
| Illuminator Number | 4 (IR light); 1 (Warm light); 8 (Laser) |
| Wiper | Smart wiper |
| Lens |
| Focal Length | 6.0 mm–252 mm |
| Max. Aperture | F1.4–F4.8 |
| Field of View | H: 66.1°–2.2°; V: 39.0°–1.3°; D: 74.1°–2.5° |
| Optical Zoom | 42× |
| Focus Control | Auto; Semi-auto; Manual |
| Close Focus Distance | 0.5 m–2 m (1.64 ft–6.56 ft) |
| Iris Control | Auto/Manual/Iris Prio |
| DORI Distance | |
| Lens | Detect | Observe | Recognize | Identify |
| W | 120 m
( 393.70 ft) | 47.4 m
( 155.51 ft) | 24 m
( 78.74 ft) | 12 m
( 39.37 ft) |
| T | 5040 m
( 16535.43 ft) | 1990.8 m
( 6531.50 ft) | 1008 m
( 3307.09 ft) | 504 m
( 1653.54 ft) |
|
| PTZ |
| Pan/Tilt Range | Pan: 0° to 360° endless, smart pan-tilt correction;
Tilt: –20° to +90°, auto flip 180°, smart pan-tilt correction |
| Manual Control Speed | Pan: 0.1°/s–240°/s;
Tilt: 0.1°/s–100°/s |
| Preset Speed | Pan: 240°/s;
Tilt: 100°/s |
| Preset | 300 |
| Tour | 8 (up to 32 presets per tour) |
| Pattern | 5 |
| Scan | 5 |
| Power-off Memory | Yes |
| Idle Motion | Preset; Pattern; Tour; Scan |
| PTZ Protocol | Pelco-P/D (auto recognition) |
| Smart pan-tilt correction | YES |
| Intelligence |
| Video Metadata | Supports detection of motor vehicles, non-motor vehicles, faces and human bodies, optimization,
capturing pictures, and uploading high-quality face snapshots.
It extracts attributes from motor vehicles and non-motors,
detecting up to 10 attributes for motor vehicles and 8 for non-motor vehicles.
It also extracts attributes from human faces and bodies, detecting up to 6 attributes for faces, and 8 for bodies |
| IVS (Perimeter Protection) | Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving;
parking detection; people gathering; human and vehicle alarm classification;
detail camera linkage for positioning and tracking when multiple rules are triggered; cascaded video metadata;
linkage tracking; privacy protection |
| Face Recognition | Supports face detection, optimization, capturing pictures, uploading high-quality face snapshots and enhancing face images.
Attribute extraction is also supported, where 6 attributes and 8 expressions can be detected.
Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo.
It supports up to 5 face databases, where people can be added one by one or in batches.
The face similarity can also be set, and faces can be compared against 10,000 faces |
| Smart Tracking | WizTracking |
| AcuPick | Uses deep learning algorithms and works with backend devices to accurately match targets,
such as people and motor vehicles, and search through live and recorded videos to quickly locate targets |
| Privacy Protection | For public scenes, mosaics can be used in real time to block detected human faces or body parts
on the monitoring screen while people are moving to protect the privacy of special groups. |
| Video |
| Video Compression | Smart H.265+;H.265;Smart H.264+;H.264;H.264B;H.264H;MJPEG(Sub Stream 1) |
| Streaming Capability | 3 streams |
| Resolution | 8M (3840 × 2160); 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960);
720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Video Frame Rate | Main stream: 8M/4M/1080p/1.3M/720p@(1–25/30 fps)
Sub stream 1: D1/VGA/CIF@(1–25/30 fps)
Sub stream 2: 1080p/1.3M/720p/CIF@(1–25/30 fps) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H264: 128 kbps–16384 kbps
H265: 51 kbps–11776 kbps |
| Day/Night | Auto/Color/B/W/Electronic |
| BLC | Yes |
| WDR | 120 dB |
| HLC | Yes |
| White Balance | Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp |
| Gain Control | Auto; Manual; Gain Prio |
| Noise Reduction | 2D NR; 3D NR |
| Motion Detection | Yes |
| Region of Interest (RoI) | Yes |
| Image Stabilization | Gyroscope EIS |
| Defog | Optical |
| Digital Zoom | 16× |
| Image Rotation | 180° |
| Privacy Masking | Up to 24 areas can be set, with up to 8 areas in the same view; color block and mosaic selectable |
| S/N Ratio | ≥ 55 dB |
| Audio |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G722.1; G729; G723 |
| Network |
| Network Port | RJ-45 (10/100 Base-T) |
| Network Protocol | HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;IPv6;802.1x;SSL;QoS;
FTP;UPnP;ICMP;SNMP;IGMP;ARP;RTCP;RTP;PPPoE;RTMP;Bonjour;NFS |
| Interoperability | ONVIF (Profile S & Profile G & Profile T);CGI;SDK |
| Streaming Method | Unicast/Multicast |
| User/Host | 20 (total bandwidth: 64 M) |
| Storage | Micro SD card (512 GB); FTP; NAS |
| Browser | IE 9 and later versions
Chrome 41 and later versions
Firefox 50 and later versions
Safari 10 and later versions |
| |
| Mobile Client | iOS;Android |
| Certification |
| Certifications | CE |
| Port |
| Analog Output | 1 channel (CVBS output, BNC) |
| RS-485 | 1 (baud rate: 1200 bps–9600 bps) |
| Audio Input | 1 channel (LINE IN, bare wire) |
| Audio Output | 1 channel (LINE OUT,bare wire) |
| Alarm Input | 7 (on-off value input: 0–5 VDC) |
| Alarm Output | 2 channels |
| Alarm Linkage | Capture; preset; tour; pattern; recording; alarm digital output; send email; audio |
| Alarm Event | Motion/tampering detection; audio detection; network disconnection detection;
IP conflict detection; memory card state detection; memory space detection |
| Power |
| Power Supply | 36 VDC; 2.23 A (±25%)PoE (802.3bt) |
| Power Consumption | Basic: 17 W
Max. (Illuminator + PTZ operation + Wiper operation): 41 W |
| Power Adapter | Included |
| Environment |
| Operating Temperature | –40 °C to +70 °C (–40 °F to +158 °F) |
| Operating Humidity | ≤ 95% |
| Protection | IP67;IK10;TVS 6000 V lightning proof; surge protection; voltage transient protection |
| Anti-corrosion Level | Basic Protection
*The products are designed for general use and are applicable even in areas
with no specific requirements for anti-corrosion protection. |
| Structure |
| Product Dimensions | 262 mm × 262 mm × 442 mm (10.31" × 10.31" × 17.40") (L × W × H) |
| Net Weight | 10.38 kg (22.88 lb) |
| Gross Weight | 13.83 kg (30.49 lb) |
