| Camera |
| Image Sensor | 1/2.8" CMOS |
| Pixel | 4 MP |
| Max. Resolution | 2560 (H) × 1440 (V) |
| ROM | 4 GB |
| RAM | 2 GB |
| Electronic Shutter Speed | 1s–1/30000s |
| Scanning System | Progressive |
| Min. Illumination | 0.005 lux@F1.6 (Color, 30 IRE)
0.0005 lux@F1.6 (B/W, 30 IRE)
0 lux (Illuminator on) |
| Illumination Distance | 100 m (328.08 ft) (Warm light);
250 m (820.21 ft) (IR) |
| Illuminator On/Off Control | Zoom Prio; Manual; Auto; Off |
| Illuminator Number | 6 (Dual light fusion) |
| Lens |
| Focal Length | 3.95 mm–177.25 mm |
| Max. Aperture | F1.6–F4.95 |
| Field of View | H: 70.3°–1.8°; V: 37°–1°; D: 69.3°–2° |
| Optical Zoom | 45× |
| Focus Control | Auto; Semi-auto; Manual |
| Close Focus Distance | 0.1 m–1 m (0.33 ft–3.28 ft) |
| Iris Control | Auto; Manual; Iris prio |
| DORI Distance | |
| Lens | Detect | Observe | Recognize | Identify |
| W | 79.0 m
( 259.19 ft) | 31.2 m
( 102.38 ft) | 15.8 m
( 51.84 ft) | 7.9 m
( 25.92 ft) |
| T | 3555.0 m
( 11663.39 ft) | 1404.2 m
( 4607.04 ft) | 711.0 m
( 2332.68 ft) | 355.5 m
( 1166.34 ft) |
| PTZ |
| Pan/Tilt Range | Pan: 0° to 360° endless; Tilt: –20° to +90°, auto flip 180° |
| Manual Control Speed | Pan: 0°/s–260°/s; Tilt: 0°/s–140°/s |
| Preset Speed | Pan: 300°/s; Tilt:200°/s |
| Preset | 300 |
| Tour | 8 |
| Pattern | 5 |
| Scan | 5 |
| Power-off Memory | Yes |
| Idle Motion | Preset;Pattern;Tour;Scan |
| PTZ Protocol | DH-SDPelco-P/D(Auto recognition) |
| Intelligence |
| Video Metadata | Supports detection of motor vehicles, non-motor vehicles, faces and human bodies, optimization,
capturing pictures, and uploading high-quality face snapshots.It extracts attributes from motor vehicles and non-motors,
detecting up to 10 attributes for motor vehicles and 8 for non-motor vehicles.
It also extracts attributes from human faces and bodies, detecting up to 6 attributes for faces, and 8 for bodies. |
| IVS (Perimeter Protection) | Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving;
parking detection; people gathering; human alarm classification; linkage tracking |
| Face Detection | Supports face detection, optimization, capturing pictures, uploading high-quality face snapshots and enhancing face images.
Attribute extraction is also supported, where 6 attributes and 8 expressions can be detected. Face cutout is also offered,
where you can cutout one face at a time and customize the size to be a one-inch photo.
The supported methods for capturing snapshots are real-time capturing, quality first, and selecting a preferred image
among a group of snapshots. |
| Construction Monitoring | Detects 6 helmet colors: Red, orange, yellow, blue, white, and black.
An alarm will be triggered when a person is not wearing a helmet or when the color of the helmet that
they are wearing does not match the configured color.
It also supports compliance detection for work uniforms.
Up to 5 work uniform sample libraries can be uploaded, which together can contain up to 1,000 images
(the images must be 1080p and in the JPG format).
An alarm will be triggered when the similarity between the detected work uniform and the samples
in the library is below the set threshold (that is, below the minimum compliance standard for work uniforms).
The system supports detecting the attributes of work uniforms such as the color of the uniform,
and whether or not the person is wearing a mask and wearing shoe covers.
An alarm will be triggered when the target is detected as not meeting the set requirements.
It also detects and triggers alarms when only one person is in the construction site,
and when no one is present in the detection area such as when a worker leaves their post or an area is left unmanned. |
| Smart Tracking | WizTracking |
| SMD | SMD 4.0 |
| AcuPick | Uses deep learning algorithms and works with backend devices to accurately match targets,
such as people and motor vehicles, and search through live and recorded videos to quickly locate targets |
| Auto Patrol | After an IVS event occurs, the PTZ camera immediately initiates automated patrol of predefined key points to
quickly cover potential risk areas and detect unknown threats in real time. |
| Active Deterrence |
| Light Warning | Red and blue warning lightFlash duration: 5 s–30 sFlash frequency: high, medium, low |
| Sound Warning | Built in 11 voice alarm contents, supporting custom import of 10 voice contents; Sound: 0-100 adjustable;
The playback frequency can be adjusted from 1 to 10 times; (requires external speaker for use) |
| Video |
| Video Compression | Smart H.265+;H.265;Smart H.264+;H.264;H.264B;H.264H;MJPEG(Sub Stream 1) |
| Streaming Capability | 3 streams |
| Resolution | 4M (2560 × 1440); 3M (2304 × 1296); 1080p (1920 × 1080); 960p (1280 × 960); 720p (1280 × 720);
D1 (704 × 576/704 × 480); VGA（640 × 480); CIF (352 × 288/352 × 240) |
| Video Frame Rate | Main stream: 4M/1080p/1.3M/720p@(1–25/30 fps)
Sub stream 1: D1/VGA/CIF@(1–25/30 fps)
Sub stream 2: 1080p/1.3M/720p/@(1–25/30 fps) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H264: 96 kbps–15104 kbps
H265: 38 kbps–9216 kbps |
| Day/Night | Auto (ICR)/Color/B/W |
| BLC | Yes |
| WDR | 120 dB |
| HLC | Yes |
| White Balance | Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp |
| Gain Control | Auto; manual; gain prio |
| Noise Reduction | 2D NR; 3D NR |
| Motion Detection | Yes |
| Region of Interest (RoI) | Yes |
| Image Stabilization | Electronic Image Stabilization (EIS) |
| Defog | Electronic |
| Digital Zoom | 16x |
| Image Rotation | 180° |
| Privacy Masking | Up to 24 areas can be set, with up to 8 areas in the same view
Multiple colors and mosaic available |
| S/N Ratio | ≥55 dB |
| Audio |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 |
| Built-in Speaker | Yes |
| Network |
| Network Port | RJ-45 (10/100 Base-T) |
| Network Protocol | HTTP;HTTPS;TCP/IP;IPv4;RTSP;UDP;SMTP;NTP;DHCP;DNS;DDNS;IPv6;802.1x;SSL;QoS;FTP;UPnP;
ICMP;SNMP;IGMP;ARP;RTCP;RTP;PPPoE;RTMP;Bonjour;SMB;NFS |
| Interoperability | ONVIF (Profile S & Profile G & Profile T);CGI;SDK |
| Streaming Method | Unicast/Multicast |
| User/Host | 20 (total bandwidth: 64 M) |
| Storage | Micro SD card (512 GB); FTP/SFTP; NAS |
| Browser | IE 9 and later versions
Chrome 41 and later versions
Firefox 50 and later versions
Safari 10 and later versions |
| Management Software | DMSS;DSS Pro |
| Mobile Client | iOS;Android |
| Port |
| RS-485 | 1 (Bit range: 1200 bps–9600 bps) |
| Audio Input | 1 channel (LINE IN, bare wire,built-in mic (mutually exclusive)） |
| Audio Output | 1 channel (LINE OUT,bare wire;built-in speaker (mutually exclusive)） |
| Alarm Input | 7 (on-off value input: 0–5 VDC) |
| Alarm Output | 2 channels |
| Alarm Linkage | Capture; recording; send email; preset; tour; pattern; alarm digital output; audio |
| Alarm Event | Motion/tampering detection; audio detection; network disconnection detection;
IP conflict detection; memory card state detection; memory space detection |
| Power |
| Power Supply | 24 VDC, 2.5 A ± 25%PoE+ (802.3at) |
| Power Consumption | Basic: 12 W
Max. (WDR + IR on + PTZ operation + Alarm): 21 W (24 VDC) |
| Power Adapter | Included |
| Environment |
| Operating Temperature | –40 °C to +70 °C (–40 °F to +158 °F) |
| Operating Humidity | ≤95% |
| Protection | IP67;IK10;TVS 6000 V lightning proof; surge protection; voltage transient protection |
| Structure |
| Product Dimensions | 208 mm × 202 mm × 325 mm (8.19" × 7.95" × 12.8") (L × W × H) |
| Net Weight | 4.45 kg (9.81 lb) |
| Gross Weight | 6.62 kg (14.59 lb) |
