| System |
| Main Processor | Industrial-grade processor |
| Operating System | Embedded Linux |
| Operating Interface | Web, Local GUI |
| AI |
| AI by Recorder | Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles);
perimeter protection; SMD; AcuPick; WizSeek; Texted-Defined Alarming |
| AI by Camera | Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection;
SMD; stereo analysis; crowd distribution; people counting; ANPR; heat map; PPE detection; AcuPick |
AcuPick Performance of AI by Recorder (1080P)
(Number of Channels) | Xinghan Large-Scale AI Models enabled：8 channels
Xinghan Large-Scale AI Models disabled：16 channels |
AcuPick Performance of AI by Camera (1080P)
(Number of Channels) | All channels (36 targets/s) |
| WizSeek |
| Performance | 1. Compatible with cameras that support AcuPick, it can meet full-channel WizSeek.
2. Compatible with normal cameras, after enabling AcuPick by NVR, it can offer up to 8-channel WizSeek.
3. Modeling capability: up to 432,000 targets per day. |
| Search Language | English; TradChinese; Korean |
| Perimeter Protection |
Perimeter Performance AI by Recorder
(Number of Channels) | Xinghan Large-Scale AI Models enabled：16 channels, 10 IVS rules for each channel
Xinghan Large-Scale AI Models disabled：32 channels, 10 IVS rules for each channel |
Perimeter Performance of AI by Camera
(Number of Channels) | All channels (32 targets/s) |
| Face Detection |
| Face Attributes | 6 attributes |
Face Detection Performance of AI by Recorder
(Number of Channels) | Xinghan Large-Scale AI Models enabled：8 channels (up to 12 face images/s each channel)
Xinghan Large-Scale AI Models disabled：16 channels (up to 12 face images/s each channel) |
Face Detection Performance of AI by Camera
(Number of Channels) | All channels (32 targets/s) |
| Face Recognition |
| Face Database Capacity | Up to 20 face databases with 200,000 images, with a total capacity of 44 G. |
Face Recognition Performance of AI by Recorder
(Number of Channels) | 32-channel FD (by camera) + FR (by recorder),image stream: 32 face images/s
Xinghan Large-Scale AI Models enabled：8-channel FD (by recorder) + FR (by recorder), video stream: 16 face images/s
Xinghan Large-Scale AI Models disabled：16-channel FD (by recorder) + FR (by recorder), video stream: 16 face images/s |
Face Recognition Performance of AI by Camera
(Number of Channels) | All channels (32 targets/s) |
| SMD |
| SMD Plus by Recorder | Xinghan Large-Scale AI Models enabled：Not support
Xinghan Large-Scale AI Models disabled：32 channels: Secondary filtering for human and motor vehicle,
reducing false alarms caused by leaves, rain and lighting condition change |
| SMD by Camera | All channels (64 targets/s) |
| Video Metadata |
Metadata Performance of AI by Recorder
(Number of Channels) | Xinghan Large-Scale AI Models enabled：8 channels, 23 attributes extraction.
Xinghan Large-Scale AI Models disabled：16 channels, 23 attributes extraction. |
Metadata Performance of AI by Camera
(Number of Channels) | All channels (32 targets/s) |
| People Attributes | 9 human body attributes |
| Motor Vehicle Attributes | 9 attributes |
| Non-motor Vehicle Attributes | 4 attributes |
| Vehicle License Plate Comparison |
ANPR by Camera
(Number of Channels) | All channels (32 targets/s) |
| License Plate Database Capacity | 1. Create up to 20,000 plate numbers.
2. Blocklist and allowlist |
| Audio and Video |
| Access Channel | 32 channels |
| Network Bandwidth | AI disabled: 512 Mbps incoming, 512 Mbps recording and 384 Mbps outgoing
AI enabled: 200 Mbps incoming, 200 Mbps recording and 200 Mbps outgoing |
| Resolution | 32 MP;24 MP;16 MP;12 MP;8 MP;6 MP;5 MP;4 MP;3 MP;1080p;720p;960p;D1;CIF;QCIF |
| Decoding Capability | AI disabled:
2-channel 32 MP@30 fps; 3-channel 24 MP@30 fps; 5-channel 16 MP@30 fps;
6-channel 12 MP@30 fps; 10-channel 8 MP@30 fps; 13-channel 6 MP@30 fps;
16-channel 5 MP@30 fps; 20-channel 4 MP@30 fps; 32-channel 1080p@30 fps
AI enabled:
1-channel 32 MP@30 fps; 1-channel 24 MP@30 fps; 2-channel 16 MP@30 fps;
4-channel 12 MP@30 fps; 6-channel 8 MP@30 fps; 8-channel 6 MP@30 fps;
8-channel 5 MP@30 fps; 12-channel 4 MP@30 fps; 24-channel 1080p@30 fps; 32-channel 720p@30 fps |
| Video Output | 1 VGA, 1 HDMI
VGA:1920 × 1080, 1280 × 1024, 1280 × 720
HDMI: 7680×4320, 3840 × 2160, 1920 × 1080, 1280 × 1024, 1280 × 720
Heterogeneous video source output for HDMI and VGA |
| Multi-screen Display | Main screen: 1/4/8/9/16
Sub screen: 1/4/8/9/16 |
| Third-party Camera Access | ONVIF; Panasonic; Sony; Axis; Arecont; Pelco; Canon; Hanwha |
| Compression Standard |
| Video Compression | Smart H.265+; H.265; Smart H.264+; H.264; MJPEG |
| Audio Compression | G.711a; G.711u; PCM; G726 |
| Network |
| Network Protocol | HTTP; HTTPS; TCP/IP; IPv4; IPv6; UDP; NTP; DHCP; DNS; SMTP; UPnP; IP Filter; FTP; DDNS; SNMP;
Alarm Server; P2P; Auto Registration; IP Search (Supports IP camera, DVR, NVS, etc.); ISCSI |
| Mobile Phone Access | iOS; Android |
| Interoperability | ONVIF 24.12(Profile T; Profile S; Profile G); CGI; SDK |
| Browser | Chrome; Firefox; IE |
| Recording Playback |
| Multi-channel Playback | Up to 16 channels |
| Record Mode | General; motion detection; intelligent; alarm; POS |
| Backup Method | USB device and network |
| Playback Mode | Instant playback; general playback; event playback; tag playback; smart playback |
| Storage |
| Disk Group | Yes |
| Alarm |
| General Alarm | Motion detection; local alarm; alarm box; camera external alarm; network alarm; scene changing; PIR alarm; thermal alarm |
| Anomaly Alarm | Error (no disk, disk error, low space, low quota space; abnormal disk health; network disconnection; IP conflict;
MAC conflict; abnormal fan speed); video loss; video tampering; camera offline; audio detection |
| Intelligent Alarm | Face detection; face recognition; video metadata (human, motor vehicle, and non-motor vehicle);
perimeter protection; license plate comparison |
| Alarm Linkage | Record; snapshot (panoramic); local alarm output; IPC external alarm output; audio; buzzer; log, preset; email |
| Port |
| Audio Input | 1-channel RCA |
| Audio Output | 1-channel RCA |
| Alarm Input | 4 channels |
| Alarm Output | 2 channels |
| Disk Interface | 2 SATA ports. Each disk can contain up to 20 TB.
This limit varies depending on the environment temperature. |
| RS-232 | 1 |
| RS-485 | 1 |
| USB | 2 (1 front USB 2.0 port, 1 rear USB 3.0 port) |
| HDMI | 1 |
| Network Port | 1(10/100/1000 Mbps Ethernet port, RJ-45) |
| General |
| Power Supply | 12 VDC, 4 A |
| Power Consumption | <15 W (without HDD) |
| Net Weight | 1.65 kg (3.64 lb) |
| Gross Weight | 3.19 kg (7.03 lb) |
| Product Dimensions | 375.0 mm × 282.5 mm × 56.0 mm (14.76" × 11.12" × 2.20") (W × D × H) |
| Packaging Dimensions | 433.0 mm × 366.0 mm x 141.0 mm (17.05" × 14.41" × 5.55") (W ×D × H) |
| Operating Temperature | –10 °C to +55 °C (+14 °F to +131 °F) |
| Storage Temperature | –20 °C to +60 °C (–4 °F to +140 °F) |
| Operating Humidity | 10%–93% (RH), non-condensing |
| Certifications | CE; FCC |
