| Thermal |
| Detector Type | Vanadium oxide uncooled focal plane detector |
| Max. Resolution | 256 (H) × 192 (V) |
| Pixel Pitch | 12 μm |
| Spectral Range | 8 μm–14 μm |
| Thermal Sensitivity (NETD) | < 40 mK (@f/1.0, 25 Hz, 300 K) |
| Field of View | 2 mm: H: 87.8°; V: 63.8°
3.5 mm: H: 50.6°; V: 37.8°
7 mm: H: 24°; V: 18° |
| Close Focus Distance | 2mm: 0.3 m (0.98 ft)
3.5 mm: 0.5 m (1.64 ft)
7 mm: 1 m (3.28 ft) |
| Detection Distance① | 2 mm: Vehicle: 256 m (839.90 ft);Human: 83 m (272.31 ft)
3.5 mm: Vehicle: 449 m (1,473.10 ft);Human: 146 m (479.00 ft)
7 mm: Vehicle: 897 m (2,942.91 ft);Human: 292 m (958.01 ft) |
| Recognition Distance② | 2 mm: Vehicle: 63 m (206.69 ft);Human: 21 m (68.90 ft)
3.5 mm: Vehicle: 110 m (360.89 ft);Human: 38 m (124.67 ft)
7 mm: Vehicle: 220 m (721.78 ft);Human: 75 m (246.06 ft) |
| Identification Distance③ | 2 mm: Vehicle: 32 m (104.99 ft);Human: 11 m (36.09 ft)
3.5 mm: Vehicle: 56 m (183.73 ft);Human: 19 m (62.34 ft)
7 mm: Vehicle: 111 m (364.17 ft);Human: 38 m (124.67 ft) |
Note:①Detection Distance:
Detects objects, but cannot recognize their characteristics(objects must cover more than 3.6 pixels of the image).
②Recognition Distance: Classifies objects into general categories, such as human,vehicle (the object must cover more than 14 pixels of the image).
③Identification Distance: Classifies objects into specific categories based on theircharacteristics, such as engineering truck,
car (the object must cover more than 28pixels of the image). |
| Aperture | F1.0 |
| Digital DetailEnhancement (DDE) | Yes |
| Digital Zoom | 16 levels |
| AGC | Auto; Manual |
| Noise Reduction | 2D NR; 3D NR |
| Image Flip | 180° |
| Color Palettes | 18 (white hot/black hot/fusion/rainbow/golden autumn/midday/iron red/amber/jade/sunset/icefire
/painting/pomegranate/emerald /spring/summer/autumn/winter) |
| Fusion Mode | 3 (Warm color; Cool color; Ironred) |
| Visible |
| Image Sensor | 1/2.7'' CMOS |
| Max. Resolution | 2336 (H) × 1752 (V) |
| Pixel | 4 MP |
| Electronic Shutter Speed | 1/30,000 s–1 s |
| Min. Illumination | Color: 0.05 lux
Black & white: 0.005 lux0 lux (IR on) |
| IR Illumination Distance | 30 m (98.43 ft) |
| IR Illuminator On/Off Control | Auto; Manual |
| Aperture | 2 mm: F2.2
4 mm: F1.6
8 mm: F2.0 |
| Field of View | 2 mm: H: 94°; V: 72°
4 mm: H: 71.2°; V: 52°
8 mm: H: 33.4°; V: 25° |
| Focus Control | Fixed |
| Close Focus Distance | 2 mm: 0.3 m (0.98 ft)
4 mm: 1 m (3.28 ft)
8 mm: 2.5 m (8.2 ft) |
| Day/Night | Auto (ICR); Color; B/W |
| BLC | Yes |
| WDR | DWDR |
| HLC | Yes |
| White Balance | Auto; Manual; Indoor; Outdoor; Tracking; Street lamp; Natural |
| AGC | Auto; Manual |
| Noise Reduction | 2D NR; 3D NR |
| S/N Ratio | ≥55 dB |
| Region of Interest (RoI) | Yes |
| Image Flip | 180° |
| Exposure Compensation | Yes |
| Intelligence |
| General Intelligence | Tripwire; Intrusion |
| Advanced Intelligence | Heat Detection & Alarm
Cold & Hot Spot Trace
Human & Vehicle Classification
Smoking Detection
Call Detection |
| Temperature Measurement |
| Temperature Range | Low Temperature Mode:–20 °C to +150 °C (–4 °F to +302 °F)
High Temperature Mode:0 °C to +550 °C (+32 °F to +1022 °F) |
| Temperature Accuracy | Max (± 2 °C, ± 2%) Operating Temperature: –20 °C to +50 °C (–4 °F to +122 °F) |
| Temperature Mode | Spot: 12
Line: 12
Area: 12
Support 12 rules simultaneously |
| Video and Audio |
| Video Compression | H.265; H.264; H.264H; MJPEG |
| Resolution | Thermal:
Main Stream: 1280 × 960 (1.3M); XVGA (1024 × 768);VGA (640 × 480); 256 × 192; 1280 × 960 (by default)
Sub Stream: VGA (640 × 480); 256 × 192; 256 × 192 (by default)
Visual:
Main Stream: 2336 × 1752; 1080p (1920 × 1080); 720p (1280 × 720); D1 (704 × 576); 2336 × 1752 (by default)
Sub Stream: 720p (1280 × 720); D1 (704 × 576); CIF (352 × 288); 352 × 288 (by default) |
| Frame Rate | Thermal
50 Hz:
(main stream) 1 fps–25 fps adjustable, 25 fps by default;
(sub stream) 1 fps–25 fps adjustable, 15 fps by default
60 Hz:
(main stream) 1 fps–30 fps adjustable, 30 fps by default;
(sub stream) 1 fps–30 fps adjustable, 15 fps by default
Visual
50 Hz:
(main stream) 1 fps–25 fps adjustable, 25 fps by default;
(sub stream) 1 fps–25 fps adjustable, 15 fps by default
60 Hz:
(main stream) 1 fps–30 fps adjustable, 30 fps by default;
(sub stream) 1 fps–30 fps adjustable, 15 fps by default |
| Audio Compression | G.711a; G.711mu; PCM |
| Network |
| Protocol | HTTPS; HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE;
IPv4/v6; SNMP; QoS; UPnP; NTP |
| Edge Storage | Micro SD card (256 G) |
| Interoperability | ONVIF; CGI; DaHua SDK |
| Browser | IE: IE 8 and later
Google: 42 and earlier
Firefox: 42 and earlier |
| User/Host | 10 |
| Security | Authorized username and password; attached MAC address; encrypted HTTPS;
IEEE 802.1x; controlled network access |
| Port |
| Network | 1 × RJ-45 (10/100 Base-T) |
| Audio Input | 1 |
| Audio Output | 1 |
| Alarm Input | 2 |
| Alarm Output | 2 |
| RS-485 | 1 pair |
| Power |
| Power Supply | 12 VDC, 1.2 A ± 20%; PoE |
| Power Consumption | Basic: <3 W (12 VDC, LED off); 3.5 W (PoE)
Max: <7 W (12 VDC, LED on, heater on); 9 W (PoE) |
| Environment |
| Operating Temperature | –30 °C to +60 °C (–22 °F to +140 °F) |
| Storage Temperature | –30 °C to +70 °C (–22 °F to ﹢158 °F) |
| Operating Humidity | ≤95% |
| Protection | IP67 |
| Structure |
| Product Dimensions | 122 mm × 122 mm × 112 mm (4.80" × 4.80" × 4.41")(L × W × H) |
| Packaging Dimensions | 155 mm × 155 mm × 135 mm (6.10" × 6.10" × 5.31")(L × W × H) |
| Net Weight | ≤0.85 kg (1.87 lb) |
| Gross Weight | ≤1 kg (2.20 lb) |
| Heat Detection Distance |
| Focal Length | Max. Distance |
| 2 mm | 25 m (82.02 ft) |
| 3.5 mm | 45 m (147.64 ft) |
| 7 mm | 86 m (282.15 ft) |
Note:
The table displays the measured distances obtained from using the target size0.2 m × 0.2 m for testing in an environment
where the temperature is 23 °C and the relative humidity is below 60%.The table is for reference only.
The distances within it are subject to actual conditions including atmospheric conditions, target size, the installation site, and more. |
| Temperature Measurement Range |
| Focal Length | Min. Distance | Max. Distance |
| 2 mm | 0.5 m (1.64 ft) | 2.5 m (8.20 ft) |
| 3.5 mm | 1 m (3.25 ft) | 5 m (16.40 ft) |
| 7 mm | 2 m (6.56 ft) | 8 m (26.25 ft) |
Note:
The table displays the measured distances obtained from using the target size0.1 m × 0.1 m for testing in an environment
where the temperature is 23 °C and the relative humidity is below 60%.The table is for reference only.
The distances within it are subject to actual conditions including atmospheric conditions, target size, the installation site, and more. |
