| Camera |
| Image Sensor | 1/1.2" CMOS |
| Max. Resolution | 3840 (H) × 2160 (V) |
| ROM | 256 MB |
| RAM | 2 GB |
| Scanning System | Progressive |
| Electronic Shutter Speed | Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination | 0.0005 lux@F1.0 |
| S/N Ratio | > 56 dB |
| Illumination Distance | Up to 60 m (196.85 ft) |
| Illuminator On/Off Control | Auto; Manual |
| Illuminator Number | 4 (Warm light) |
| Angle Adjustment | Pan: 0°–360°
Tilt: 0°–90°
Rotation: 0°–360° |
| Lens |
| Lens Type | Fixed-focal |
| Lens Mount | M22 |
| Focal Length | 2.8 mm; 3.6 mm; 6 mm |
| Max. Aperture | F1.0 |
| Field of View | 2.8 mm: H: 102°; V: 53°; D: 125°
3.6 mm: H: 88°; V: 48°; D: 104°
6 mm:H: 55°; V: 31°; D: 63° |
| Iris Control | Fixed |
| Close Focus Distance | 2.8 mm: 5 m (16.40 ft)
3.6 mm: 6 m (19.68 ft)
6 mm: 13.2 m (43.37 ft) |
| DORI Distance | Lens | Detect | Observe | Recognize | Identify |
| 2.8 mm | 95.6m (313.64 ft) | 38.2 m (125.33 ft) | 19.1 m (62.66 ft) | 9.6 m (31.50 ft) |
| 3.6 mm | 105.9 m (347.44 ft) | 42.4 m (139.11 ft) | 21.2 m (68.55 ft) | 10.6 m (34.77 ft) |
| 6 mm | 161.4 m (529.53 ft) | 64.6 m (211.94 ft) | 32.3 m (105.97 ft) | 16.1 m (52.8 ft) |
|
| Smart event |
| IVS (Perimeter Protection) | Intrusion, tripwire, fast moving (the three functions support the classification and accurate detection of vehicle and human);
loitering detection, people gathering, and parking detection |
| Smart Object Detection | Smart abandoned object; smart missing object |
| Smart Motion Detection | Smart Motion Detection 3.0 |
| Smart Pick | Uses deep learning algorithms and works with back-end devices to accurately match targets, such as people and motor vehicles,
and search through live and recorded videos to quickly locate targets. |
| Face Detection | Face detection; snapshot; snapshot optimization; optimal face snapshot upload; face enhancement; face exposure; face attributes extraction
including 6 attributes and 8 expressions; face snapshot set as face or one-inch photo; snapshot strategies (real-time snapshot, quality priority
and optimization snapshot); face angle filter; optimization time setting. |
| People Counting | Tripwire people counting and people counting in area; generating and exporting report (day/month/year);
4 rules can be set for tripwire, people counting in area and queue management. |
| Heat Map | Yes |
| Video Metadata | Motor vehicle, non-motor vehicle, face, and human body detection; snapshot; snapshot optimization; optimal face snapshot upload.
Extraction of motor vehicle and non-motor vehicle attributes:
extracts 6 attributes for motor vehicle and 6 attributes for non-motor vehicle.
Extraction of face and human body attributes: extracts 6 attributes for face and 8 attributes for human body. |
| Smart Search | Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos |
| Video |
| Video Compression | H.265; H.264; H.264H; H.264B; MJPEG (Only supported by the sub stream) |
| Smart Codec | Smart H.265+; Smart H.264+ |
| AI Coding | AI H.265; AI H.264 |
| Video Frame Rate | Main stream: 3840× 2160@(1 fps–25/30 fps)
Sub stream: D1@(1 fps–25/30 fps)
Third stream: 1080p@(1 fps–25/30 fps)
*The values above are the max. frame rates of each stream; for multiple streams, the values will be subjected to the total encoding capacity. |
| Stream Capability | 3 streams |
| Resolution | 8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520);
3.6M (2560 × 1440); 3M (2048 × 1536); 2M (2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960);
720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H.264: 32 kbps–16384 kbps
H.265: 32 kbps–16384 kbps |
| Day/Night | Color/B/W |
| BLC | Yes |
| HLC | Yes |
| WDR | 140 dB |
| Scene Self-adaptation (SSA) | Yes |
| White Balance | Auto; natural; street lamp; outdoor; manual; regional custom |
| Gain Control | Auto;Manual |
| Noise Reduction | 3D NR |
| Motion Detection | OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) | Yes (4 areas) |
| Defog | Yes |
| Image Rotation | 0°/90°/180°/270° (Support 90°/270° with 4M resolution and lower) |
| Mirror | Yes |
| Privacy Masking | 4 areas |
| LDC | Yes (only 2.8mm/3.6mm supports) |
| Audio |
| Built-in MIC | Yes, built-in dual Mic |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; G.723 |
| Built-in Speaker | Yes |
| Alarm |
| Alarm Event | No SD card; SD card full; SD card error; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire;
intrusion; fast moving; abandoned object; missing object; loitering detection; people gathering; scene changing; audio detection;
voltage detection; external alarm; face detection; Smart Motion Detection; security exception; people detection; area people counting; stay alarm;
people counting; people number exception detection |
| Network |
| Network Port | RJ-45 (10/100 Base-T) |
| SDK and API | Yes |
| Network Protocol | IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP;
DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP; P2P |
| Interoperability | ONVIF (Profile S; Profile G; Profile T); CGI |
| User/Host | 20 (Total bandwidth: 80 M) |
| Storage | FTP; SFTP; Micro SD card (support max. 512 GB); NAS |
| Browser | IE: IE 11 and later
Chrome: Chrome 45 and later
Firefox: Firefox 46 and later
Safari: Safari 12 and later |
|
| Mobile Client | iOS;Android |
| Cyber Security | Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering;
generation and importing of X.509 certification; syslog; HTTPS;802.1x; trusted boot; trusted execution; trusted upgrade |
| Certification |
| Certifications | CE; FCC |
| Port |
| Audio Input | 1 channel (RCA port) |
| Audio Output | 1 channel (RCA port) |
| Alarm Input | 1 channel in: wet contact, 5mA 3V–5V DC |
| Alarm Output | 1 channel out: wet contact, 300mA 12V DC |
| Power |
| Power Supply | 12 VDC/POE + (802.3at)/ePoE |
| Dual Power Backup | When the power adapter and PoE provide power at the same time, disconnect one of them.
The device will continue to work, but will not restart. |
| Power Consumption | Basic: 4 W (12 VDC); 5.4 W (PoE)
Max. (H.265+ warm light+ intelligence on + WDR): 12.9 W (12 VDC); 14.5 W (PoE) |
| Environment |
| Operating Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Operating Humidity | ≤ 95% |
| Storage Temperature | –40 °C to +60 °C (–40 °F to +140 °F) |
| Protection | IP67 |
| Storage Humidity | 10%–95% (RH), non-condensing |
| Structure |
| Casing Material | Metal |
| Product Dimensions | 288.4 mm × 94.4 mm × 90.4mm (11.35" × 3.72" × 3.60") (L × W × H) |
| Net Weight | 1150 g (2.53 lb) |
| Gross Weight | 1330 g (2.93 lb) |
