| Camera |
| Image Sensor | 1/2.8" CMOS |
| Pixel | 8 MP |
| Max. Resolution | 3840 (H) × 2160 (V) |
| ROM | 4 GB |
| RAM | 1 GB |
| Electronic Shutter Speed | 1 s–1/30,000 s |
| Scanning System | Progressive |
| Min. Illumination | 0.005 lux@F1.6 (Color, 30 IRE);
0.0005 lux@F1.6 (B/W, 30 IRE);
0 lux (illuminator on) |
| Illumination Distance | 100 m (328.08 ft) (IR);
50 m (164.04 ft) (White light) |
| Illuminator On/Off Control | Zoom Prio; Manual; Auto; Off |
| Illuminator Number | 2 (IR); 2 (Dual light fusion) |
| Lens |
| Focal Length | 5 mm–125 mm |
| Max. Aperture | F1.6-F3.6 |
| Field of View | H: 53.1°-3.4°; V: 30.4°-1.9°; D: 59.3°-3.9° |
| Optical Zoom | 25 × |
| Focus Control | Auto; semi-auto; manual |
| Close Focus Distance | 0.1m-1.5 m (0.33 ft–4.92 ft) |
| Iris Control | Auto; manual |
| DORI Distance | Detect | Observe | Recognize | Identify |
| 3310 m (10859.58 ft) | 1308 m (4291.34 ft) | 662 m(2171.92 ft) | 331 m (1085.96 ft) |
| PTZ |
| Pan/Tilt Range | Pan: 0° to 360° endless;
Tilt: –15° to +90°, auto flip 180° |
| Manual Control Speed | Pan: 0.1°/s–200°/s;
Tilt: 0.1°/s–120°/s |
| Preset Speed | Pan: 0.1°/s–240°/s;
Tilt: 0.1°/s–200°/s |
| Preset | 300 |
| Tour | 8 (up to 32 presets per tour) |
| Pattern | 5 |
| Scan | 5 |
| Power-off Memory | Yes |
| Idle Motion | Pattern; Preset; Scan; Tour |
| Intelligence |
| IVS (Perimeter Protection) | Tripwire; intrusion; crossing fence detection; loitering detection; abandoned/missing object; fast moving; parking detection; people gathering; linkage tracking |
| Face Detection | Supports face detection, optimization, capturing pictures, uploading high-quality face snapshots and enhancing face images.
Attribute Extraction is also supported, where 6 attributes and 8 expressions can be detected.
Face cutout is also offered, where you can cutout one face at a time and customize the size to be a one-inch photo.
The supported methods for capturing snapshots are real-time capturing, quality first, and selecting a preferred image among a group of snapshots |
| Auto Tracking | Yes |
| SMD | SMD 4.0 |
| Auto Patrol | It triggers the IVS rule when a target is detected and makes the camera link with the PTZ to rotate to the position of the target and patrol based on its presets |
| Active Deterrence |
| Light Warning | Red-blue light warning
Flash duration: 5 s–30 s
Flash frequency: high, medium, low |
| Sound Warning | Offers 11 types of sound alarms, and supports importing custom sound alarms. |
| Video |
| Video Compression | H.264H; H.264B; Smart H.265+; H.265; MJPEG (Sub Stream); Smart H.264+; H.264M |
| Streaming Capability | 3 streams |
| Resolution | 4K (3840 × 2160);
4M (2560 × 1440);
3M (2048 × 1536);
3M (2304 × 1296);
1080p (1920 × 1080);
1.3M (1280 × 960);
720p (1280 × 720);
D1 (704 × 576/704 × 480);
VGA (640 × 480);
CIF (352 × 288/352 × 240) |
| Video Frame Rate | Main stream: 4K/4M/3M/1080p/1.3 M/720p@(1–25/30 fps)
Sub stream 1: D1/CIF/VGA@(1–25/30 fps)
Sub stream 2: 1080p/1.3 MP/720p@(1–25/30 fps) |
| Bit Rate Control | CBR/VBR |
| Video Bit Rate | H264: 128 Kbps–16,384 Kbps
H265: 128 Kbps–11,776 Kbps |
| Day/Night | Auto (ICR); Color/B/W |
| BLC | Yes |
| WDR | DWDR |
| HLC | Yes |
| White Balance | Auto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp |
| Gain Control | Auto; manual |
| Noise Reduction | 2D NR; 3D NR |
| Motion Detection | Yes |
| Region of Interest (RoI) | Yes |
| Image Stabilization | Electronic (EIS) |
| Defog | Electronic |
| Digital Zoom | 16× |
| Image Rotation | 180° |
| Privacy Masking | Up to 24 areas can be set, with up to 8 areas in the same view;Multiple colors available |
| S/N Ratio | ≥ 55 dB |
| Audio |
| Audio Compression | PCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723 |
| Network |
| Network Port | RJ-45 (10/100 Base-T) |
| Network Protocol | FTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP; UDP; IGMP; HTTP; SSL; DHCP; SMTP; Qos; RTSP; ARP |
| Interoperability | ONVIF (Profile S & Profile G & Profile T); CGI; SDK; P2P |
| Streaming Method | Unicast/Multicast |
| User/Host | 20 (total bandwidth: 64 M) |
| Storage | Micro SD card (512 GB); FTP/SFTP; NAS |
| Browser | IE 9 and later versions;
Chrome 41 and later versions;
Firefox 50 and later versions;
Safari 10 and later versions |
| Management Software | DMSS; DSS Pro |
| Mobile Client | iOS; Android |
| Certification |
| Certifications | CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014 |
| Port |
| Audio Input | 1 channel (LINE IN, bare wire) |
| Audio Output | 1 channel (LINE OUT,bare wire;built-in speaker (mutually exclusive)) |
| Alarm Input | 2 (on-off value input: 0–5 VDC) |
| Alarm Output | 1 channel |
| Alarm Linkage | Capture; recording; send email; preset; tour; pattern; alarm digital output; audio; warning light |
| Alarm Event | Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card state detection; memory space detection |
| Power |
| Power Supply | 12 VDC, 3 A ± 10%;
PoE+ (802.3at) |
| Power Consumption | 12 VDC:
Basic: 8 W;
Max: 16 W (white light + heated glass + PTZ on + alarm + red and blue light flashing)
POE:
Basic: 9 W;
Max: 17 W (white light + heated glass + PTZ on + alarm + red and blue light flashing) |
| Environment |
| Operating Temperature | –40 °C to +65 °C (–40 °F to +149 °F) |
| Operating Humidity | ≤ 95% |
| Protection | TVS 6000 V lightning proof; IP66; surge protection; voltage transient protection |
| Structure |
| Product Dimensions | 269.9 mm × Φ160.0 mm (10.63" × Φ6.30") |
| Net Weight | 2.6 kg (5.73 lb) |
| Gross Weight | 4 kg (8.82 lb) |
