EmpireTech PTZ5A4K-25X 1/1.8" CMOS 8MP 25x Starlight IR 5.4mm–135mm Vari-Focal PTZ Camera Supports Auto-tracking-3.0

$799.99
$849.99
$799.99
1/1.8" 8Megapixel CMOS | Powerful 25x optical zoom. | Starlight+ Technology | Max. 25/30fps@8MP | IR distance up to 150 m | Auto Tracking 3.0 | SMD 4.0 | Quick Pick | PoE+ | IP67, IK10
Payment :
your-image
Share :
your-image your-image your-image
EmpireTech PTZ5A4K-25X 1/1.8" CMOS 8MP 25x Starlight IR Network PTZ Camera Support Auto-tracking-3.0 SMD-4.0 Quick Pick - EmpireTech

EmpireTech PTZ5A4K-25X 1/1.8" CMOS 8MP 25x Starlight IR 5.4mm–135mm Vari-Focal PTZ Camera Supports Auto-tracking-3.0

$849.99 $799.99

EmpireTech PTZ5A4K-25X 1/1.8" CMOS 8MP 25x Starlight IR 5.4mm–135mm Vari-Focal PTZ Camera Supports Auto-tracking-3.0

$849.99 $799.99

8MP 25x Starlight IR Network PTZ Camera

  • 1/1.8" 8Megapixel CMOS.
  • Powerful 25x optical zoom.
  • Starlight+ Technology.
  • Max. 25/30fps@8MP.
  • IR distance up to 150 m.
  • Deep-learning-based perimeter protection.
  • Auto Tracking 3.0.
  • SMD 4.0.
  • Quick Pick.
  • PoE+.
  • IP67, IK10.

Installation Type

Packing List Included: PFB305W Wall Mount
Optional Accessories(Mount needs to be purchased separately):







Product Specs
Camera
Image Sensor1/1.8" CMOS
Pixel4K
Max. Resolution3840(H) x 2160(V)
ROM4 GB
RAM1 GB
Electronic Shutter Speed1 s–1/30,000 s
Scanning SystemProgressive
Min. IlluminationColor: 0.005 lux@F1.6
B/W: 0.0005 lux@F1.6
0 lux@F1.6 (IR light on)
Illumination Distance150 m (492.13 ft) (IR)
Illuminator On/Off ControlZoom Prio; Manual; Auto; Off
Illuminator Number4 (IR)
Lens
Focal Length5.4 mm–135 mm
Max. ApertureF1.6–F4.0
Field of ViewH: 61.6°–3.6°; V: 35.7°–2°; D: 66.6°–4°
Optical Zoom25×
Focus ControlAuto; semi-auto; manual
Close Focus Distance0.1 m–2 m
Iris ControlAuto; manual; fixed
DORI DistanceDetectObserveRecognizeIdentify
2700 m (8858.27 ft)1066 m (3497.38 ft)540 m (1771.65 ft)270 m (885.83 ft)
PTZ
Pan/Tilt RangePan: 0° to 360° endless
Tilt: –15° to +90°, auto flip 180°
Manual Control SpeedPan: 0.1°/s–300°/s
Tilt: 0.1°/s–140°/s
Preset SpeedPan: 400°/s; Tilt: 300°/s
Preset300
Tour8 (up to 32 presets per tour)
Pattern5
Scan5
Power-off MemoryYes
Idle MotionPattern; Preset; Scan; Tour
PTZ ProtocolDH-SD Pelco-P/D (Auto recognition)
Intelligence
IVS (Perimeter Protection)Tripwire; intrusion; climbing fences; loitering detection; abandoned/missing object; fast moving; parking detection;
people gathering; vehicle/human alarm classification; linkage tracking
Face DetectionSupports face detection,face bounding box, capturing snapshots, uploading face snapshots, enhancing face images,
and selecting a preferred image among a group of snapshots. Attribute Extraction is also supported, where 6 attributes
and 8 expressions can be detected. The attributes are gender, age, glasses, mask, mustache and expressions. The
expressions are angry, sad, hate, scared, surprised, calm, happy and confused. Face cutout is also offered, where you can
cutout one face at a time and customize the size to be a one-inch photo. The supported methods for capturing snapshots
are real-time capturing, quality first, and selecting a preferred image among a group of snapshots.
Auto TrackingYes
Quick PickWith AI NVR, quickly pick up the human/vehicle targets that users are interested in from SMD events.
SMDYes
Video
Video CompressionH.265; H.264B; H.264; H.264H; MJPEG(Sub Stream 1); smart H.265+; smart H.264+
Streaming Capability3 streams
Resolution4K (3840 × 2160); 4M (2560 × 1440); 3M (2048 × 1536); 1080p (1920 × 1080); 960p (1920 × 960); 720p (1280 × 720);
D1 (704 × 576/704 × 480); CIF (352 × 288/352 × 240); VGA (640 × 480)
Video Frame RateMain stream: 8M/4M/3M/1080p/1.3M/720p (1–25/30 fps)
Sub stream 1: D1/CIF/VGA (1–25/30 fps)
Sub stream 2: 1080p/1.3M/720p (1–25/30 fps)
Bit Rate ControlCBR/VBR
Video Bit RateH.264: 128 kbps–16,384 kbps
H.265: 51 kbps–12,288 kbps
Day/NightAuto (ICR)/Color/B/W
BLCYes
WDR120 dB
HLCYes
White BalanceAuto; indoor; outdoor; tracking; manual; sodium lamp; natural light; street lamp
Gain ControlAuto; manual
Noise Reduction2D NR; 3D NR
Motion DetectionYes
Region of Interest (RoI)Yes
Image StabilizationElectronic(EIS)
DefogElectronic
Digital Zoom16×
Image Rotation180°
Privacy MaskingUp to 24 areas can be set, with up to 8 areas in the same view;multiple colors available
S/N Ratio≥ 55 dB
Audio
Audio CompressionPCM; G.711a; G.711Mu; G.726; MPEG2-Layer2; G722.1; G729; G723
Network
Network PortRJ-45 (10/100 Base-T)
Network ProtocolFTP; RTMP; IPv6; Bonjour; IPv4; DNS; RTCP; PPPoE; NTP; RTP; 802.1x; HTTPS; SNMP; TCP/IP; DDNS; UPnP; NFS; ICMP;
UDP; IGMP; HTTP; SSL; DHCP; SMTP; Qos; RTSP; ARP
InteroperabilityONVIF(Profile S&G&T);CGI;SDK
Streaming MethodUnicast/Multicast
User/Host20 (total bandwidth: 64 M)
StorageMicro SD card (512 GB); FTP/SFTP; NAS
BrowserIE 9 and later versions
Chrome 41 and later versions
Firefox 50 and later versions
Safari 10 and later versions
Management SoftwareDMSS; DSS Pro
Mobile ClientiOS; Android
Certification
CertificationsCE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014
UL: UL60950-1+CAN/CSA C22.2,No.60950-1
Port
Audio Input1 channel (LINE IN, bare wire)
Audio Output1 channel (LINE OUT, bare wire)
Alarm LinkageCapture; recordings; send email; preset; tour; pattern; alarm digital input
Alarm EventMotion/tampering detection; audio detection; network disconnection detection; IP conflict detection; memory card
status detection; memory space detection
Alarm I/O2/1
Audio I/O1/1
Power
Power Supply24 VDC/2.5 A ± 25%
PoE+ (802.3at)
Power ConsumptionBasic: 12W
Max: 21W(IR light+PTZ+Heater+Fan)
Environment
Operating Temperature–40 °C to +70 °C (–40 °F to +158 °F)
Operating Humidity≤ 95%
Storage Temperature–40 °C to +70 °C (–40 °F to +158 °F)
Storage Humidity≤ 95%
ProtectionIP67, IK10, TVS 6000 V lightning proof; surge protection; voltage transient protection
Structure
Product DimensionsΦ190 mm × 332 mm (Φ7.48" × 13.07")
Net Weight4.7 kg (10.36 lb)
Gross Weight8.0 kg (17.64 lb)


Customer Reviews

Based on 1 review
100%
(1)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
S
SteveOzz
Very Good Camera!

I've got three other network cameras all the same brand (mini 4x Starlight PTZ dome, two 4x zoom bullets; 4K NC and 8K Starlight enhanced) and the PTZ5A4K-25X has the best day/night image. Daytime viewing set to auto is crystal clear, vivid colors with no barrel or edge distortion. A slight halo effect in day/night viewing but only noticeable at zero zoom. Night time surveillance in color can't compare with my NC bullet but it's pretty impressive with just a distance street light or a few garden lights. IR illumination is amazing! My mini dome is good to about 50' and somewhat blurry but the PTZ5A4K-25X can sharply light up a dark house a half block away! Being 1/1.8" @ 4 MP with manual iris control means I can easily remove most motion blur/ghosting in low light conditions keeping the gain/NR set low while maintaining a high shutter speed. My other cameras struggle auto focusing in low light or IR illumination only but the PTZ5A4K-25X is excellent, no need playing around with manual focus. PT is very fast and super quiet. PFA zooming works as advertised. Auto tracking once setup correctly works most of the time depending on the speed of the target, lighting conditions and size of obstacles blocking the view such as shrubs, parked cars etc. FOV is quite narrow so I had to mount it about 20' up just to get my front yard in view. Network speed is excellent. IP67 rated so no internal microphone. The camera housing including the black sphere is all aluminum, no plastic, and the lens protector appears to be glass. The included wall mount bracket is one beefy piece of aluminum! Trust me, the eyelet can easily hold the PTZ5A4K-25X by the included steel cable hook. Free shipping to Canada with tracking was fast. Mine arrived very well boxed with the camera wrapped in plastic and placed in rigid foam. It included a 24V DC 2.5A adapter but I used PoE+ instead. No branding apart from a small silver EmpireTech sticker on the back. EmpireTech customer support is excellent.
